INA KWSE20-H-V1-G3

INA KWSE20-H-V1-G3
INA KWSE20-H-V1-G3 rulman resim 1
INA KWSE20-H-V1-G3 rulman resim 2
INA KWSE20-H-V1-G3 rulman resim 3
INA KWSE20-H-V1-G3 rulman resim 4
INA KWSE20-H-V1-G3 rulman resim 5
Fiyatı: 2,882.93 ₺
Özellikler
Marka INA
Ürün No KWSE20-H-V1-G3 INA
Üretici No 0007729330240
Alternatif Kodu KWSE20-H-G3-V1
EAN 4054362939511
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 20
Dış (D) MM 44
En (B) MM 70,9
İç (d) Inch 0.7874
Dış (D) Inch 1.7323
En (B) Inch 2.7913
Ağırlık 0.32 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 44
Overall length carriage (L) mm 71,4
Dynamic load rating, load direction I: compressive load (I C) 22000
Static load rating, load direction I: compressive load (I C 0) 52000
Dynamic load rating, load direction II: tensile load (II C) 21300
Static load rating, load direction II: tensile load (II C 0) 35300
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 21000
Static load rating, Load direction III: lateral load (III C 0) 35000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
H High Carriage
V1 Slight Preload
G3 Precision Class 3
