INA KWSE20-V0-G2
Fiyatı: 3,541.85 ₺
Özellikler
| Marka | INA |
| Ürün No | KWSE20-V0-G2 INA |
| Üretici No | 0007729250130 |
| Alternatif Kodu |
KWSE20-G2-V0 |
| EAN | 4054362941392 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 63 |
| En (B) MM | 70,9 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.4803 |
| En (B) Inch | 2.7913 |
| Ağırlık | 0.43 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 63 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating, load direction I: compressive load (I C) | 22000 |
| Static load rating, load direction I: compressive load (I C 0) | 52000 |
| Dynamic load rating, load direction II: tensile load (II C) | 21300 |
| Static load rating, load direction II: tensile load (II C 0) | 35300 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) | 21000 |
| Static load rating, Load direction III: lateral load (III C 0) | 35000 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
