INA KWSE25-H-V0-G2

INA KWSE25-H-V0-G2
INA KWSE25-H-V0-G2 rulman resim 1
INA KWSE25-H-V0-G2 rulman resim 2
INA KWSE25-H-V0-G2 rulman resim 3
INA KWSE25-H-V0-G2 rulman resim 4
INA KWSE25-H-V0-G2 rulman resim 5
Fiyatı: 3,709.74 ₺
Özellikler
Marka INA
Ürün No KWSE25-H-V0-G2 INA
Üretici No 0007729840130
Alternatif Kodu KWSE25-H-G2-V0
EAN 4054362945246
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 23
Dış (D) MM 48
En (B) MM 81,8
İç (d) Inch 0.9055
Dış (D) Inch 1.8898
En (B) Inch 3.2205
Ağırlık 0.5 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 48
Overall length carriage (L) mm 81,8
Dynamic load rating, load direction I: compressive load (I C) 28000
Static load rating, load direction I: compressive load (I C 0) 67000
Dynamic load rating, load direction II: tensile load (II C) 26000
Static load rating, load direction II: tensile load (II C 0) 45000
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 28000
Static load rating, Load direction III: lateral load (III C 0) 47000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
H High Carriage
V0 Little To No Preload
G2 Precision Class 2
