INA KWSE30-L-V0-G2
Fiyatı: 5,108.36 ₺
Özellikler
| Marka | INA |
| Ürün No | KWSE30-L-V0-G2 INA |
| Üretici No | 0028659390130 |
| Alternatif Kodu |
KWSE30-L-G2-V0 |
| EAN | 4054362952411 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| Dış (D) MM | 90 |
| En (B) MM | 119,1 |
| İç (d) Inch | 1.1024 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 4.689 |
| Ağırlık | 1.6 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 119,3 |
| Dynamic load rating, load direction I: compressive load (I C) | 51000 |
| Static load rating, load direction I: compressive load (I C 0) | 113000 |
| Dynamic load rating, load direction II: tensile load (II C) | 48000 |
| Static load rating, load direction II: tensile load (II C 0) | 85000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) | 50000 |
| Static load rating, Load direction III: lateral load (III C 0) | 88000 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Long carriage for six-row linear recirculating ball bearing and guideway assembly |
| L | Long Carriage |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
