INA KWSE30-RROC-V1-G3
Fiyatı: 4,887.43 ₺
Özellikler
| Marka | INA |
| Ürün No | KWSE30-RROC-V1-G3 INA |
| Üretici No | 0687469380240 |
| Alternatif Kodu |
KWSE30-RROC-G3-V1 |
| EAN | 4054362953098 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| Dış (D) MM | 90 |
| En (B) MM | 91,4 |
| İç (d) Inch | 1.1024 |
| Dış (D) Inch | 3.5433 |
| En (B) Inch | 3.5984 |
| Ağırlık | 1.2 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 91,6 |
| Dynamic load rating, load direction I: compressive load (I C) | 40000 |
| Static load rating, load direction I: compressive load (I C 0) | 80000 |
| Dynamic load rating, load direction II: tensile load (II C) | 37800 |
| Static load rating, load direction II: tensile load (II C 0) | 60000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) | 40000 |
| Static load rating, Load direction III: lateral load (III C 0) | 62000 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
| RROC | Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
