INA KWSE45-V0-G2
Fiyatı: 6,894.18 ₺
Özellikler
| Marka | INA |
| Ürün No | KWSE45-V0-G2 INA |
| Üretici No | 0007732120130 |
| Alternatif Kodu |
KWSE45-G2-V0 |
| EAN | 4054362959175 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 45 |
| Dış (D) MM | 120 |
| En (B) MM | 136,7 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 4.7244 |
| En (B) Inch | 5.3819 |
| Ağırlık | 3.15 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 120 |
| Overall length carriage (L) mm | 138,7 |
| Dynamic load rating, load direction I: compressive load (I C) | 80000 |
| Static load rating, load direction I: compressive load (I C 0) | 174000 |
| Dynamic load rating, load direction II: tensile load (II C) | 72300 |
| Static load rating, load direction II: tensile load (II C 0) | 117400 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) | 76900 |
| Static load rating, Load direction III: lateral load (III C 0) | 121800 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
