INA KWVE15-B-ESC-V2-G2
Fiyatı: 1,645.67 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE15-B-ESC-V2-G2 INA |
| Üretici No | 0170654610330 |
| Alternatif Kodu |
KWVE15-B-ESC-G2-V2 |
| EAN | 4054362962212 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 15 |
| Dış (D) MM | 34 |
| En (B) MM | 44,5 |
| İç (d) Inch | 0.5906 |
| Dış (D) Inch | 1.3386 |
| En (B) Inch | 1.752 |
| Ağırlık | 0.12 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 34 |
| Overall length carriage (L) mm | 44,5 |
| Dynamic load rating (C) | 4900 |
| Static load rating (C 0) | 8300 |
| Static moment rating about X axis (M 0x) | 86 |
| Static moment rating about Y axis (M 0y) | 35 |
| Static moment rating about Z axis (M 0z) | 35 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| V2 | Preload Class 2 |
| G2 | Precision Class 2 |
