INA KWVE20-B-E-V0-G1
Fiyatı: 2,469.42 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-E-V0-G1 INA |
| Üretici No | 0658220990120 |
| Alternatif Kodu |
KWVE20-B-E-G1-V0 |
| EAN | 4054362969280 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23,5 |
| Dış (D) MM | 59 |
| En (B) MM | 71,4 |
| İç (d) Inch | 0.9252 |
| Dış (D) Inch | 2.3228 |
| En (B) Inch | 2.811 |
| Ağırlık | 0.39 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 59 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating (C) | 13100 |
| Static load rating (C 0) | 27000 |
| Static moment rating about X axis (M 0x) | 332 |
| Static moment rating about Y axis (M 0y) | 240 |
| Static moment rating about Z axis (M 0z) | 240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type |
| B | Standard Carriage, Four-Row, Full Complement Ball Set |
| E | Expanded Design (Carriage Without Screw Threads) |
| V0 | Little To No Preload |
| G1 | Precision Class 1 |
