INA KWVE20-B-N-V1-G4
Fiyatı: 2,360.48 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-N-V1-G4 INA |
| Üretici No | 0125089180250 |
| Alternatif Kodu |
KWVE20-B-N-G4-V1 |
| EAN | 4054362972495 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 63 |
| En (B) MM | 71,4 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.4803 |
| En (B) Inch | 2.811 |
| Ağırlık | 0.37 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 63 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating (C) | 13100 |
| Static load rating (C 0) | 27000 |
| Static moment rating about X axis (M 0x) | 332 |
| Static moment rating about Y axis (M 0y) | 240 |
| Static moment rating about Z axis (M 0z) | 240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-N, low carriage, four-row |
| B | Version |
| N | Low Carriage |
| V1 | Slight Preload |
| G4 | Precision Class 4 |
