INA KWVE20-B-NL-V2-G1
Fiyatı: 3,409.45 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-NL-V2-G1 INA |
| Üretici No | 0199627030320 |
| Alternatif Kodu |
KWVE20-B-NL-G1-V2 |
| EAN | 4054362971917 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 63 |
| En (B) MM | 88,9 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.4803 |
| En (B) Inch | 3.5 |
| Ağırlık | 0.51 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 63 |
| Overall length carriage (L) mm | 88,9 |
| Dynamic load rating (C) | 16200 |
| Static load rating (C 0) | 36500 |
| Static moment rating about X axis (M 0x) | 452 |
| Static moment rating about Y axis (M 0y) | 430 |
| Static moment rating about Z axis (M 0z) | 430 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-NL, low, long carriage, four-row |
| B | Version |
| NL | Low, Long Carriage |
| V2 | Preload Class 2 |
| G1 | Precision Class 1 |
