INA KWVE20-B-S-V1-G1
Fiyatı: 2,589.78 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-B-S-V1-G1 INA |
| Üretici No | 0125089260220 |
| Alternatif Kodu |
KWVE20-B-S-G1-V1 |
| EAN | 4054364003531 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 20 |
| Dış (D) MM | 44 |
| En (B) MM | 71,4 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 1.7323 |
| En (B) Inch | 2.811 |
| Ağırlık | 0.34 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 44 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating (C) | 13100 |
| Static load rating (C 0) | 27000 |
| Static moment rating about X axis (M 0x) | 332 |
| Static moment rating about Y axis (M 0y) | 240 |
| Static moment rating about Z axis (M 0z) | 240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-S, narrow carriage, four-row |
| B | Version |
| S | Narrow Carriage |
| V1 | Slight Preload |
| G1 | Precision Class 1 |
