INA KWVE20-B-V0-G1

INA KWVE20-B-V0-G1
INA KWVE20-B-V0-G1 rulman resim 1
INA KWVE20-B-V0-G1 rulman resim 2
INA KWVE20-B-V0-G1 rulman resim 3
INA KWVE20-B-V0-G1 rulman resim 4
INA KWVE20-B-V0-G1 rulman resim 5
Fiyatı: 2,709.94 ₺
Özellikler
Marka INA
Ürün No KWVE20-B-V0-G1 INA
Üretici No 0124487610120
Alternatif Kodu KWVE20-B-G1-V0
EAN 4054362976349
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 20
Dış (D) MM 63
En (B) MM 25,5
İç (d) Inch 0.7874
Dış (D) Inch 2.4803
En (B) Inch 1.0039
Ağırlık 0.44 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 63
Overall length carriage (L) mm 71,4
Dynamic load rating (C) 13100
Static load rating (C 0) 27000
Static moment rating about X axis (M 0x) 332
Static moment rating about Y axis (M 0y) 240
Static moment rating about Z axis (M 0z) 240
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B, standard carriage, four-row, full complement ball set
Suffix description
B Version
V0 Little To No Preload
G1 Precision Class 1
