INA KWVE25-B-ESC-V1-G2

INA KWVE25-B-ESC-V1-G2
INA KWVE25-B-ESC-V1-G2 rulman resim 1
INA KWVE25-B-ESC-V1-G2 rulman resim 2
INA KWVE25-B-ESC-V1-G2 rulman resim 3
INA KWVE25-B-ESC-V1-G2 rulman resim 4
INA KWVE25-B-ESC-V1-G2 rulman resim 5
Fiyatı: 2,154.65 ₺
Özellikler
Marka INA
Ürün No KWVE25-B-ESC-V1-G2 INA
Üretici No 0116942110230
Alternatif Kodu KWVE25-B-ESC-G2-V1
EAN 4054362979760
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 23
Dış (D) MM 48
En (B) MM 58,2
İç (d) Inch 0.9055
Dış (D) Inch 1.8898
En (B) Inch 2.2913
Ağırlık 0.3 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 48
Overall length carriage (L) mm 58,2
Dynamic load rating (C) 12500
Static load rating (C 0) 22200
Static moment rating about X axis (M 0x) 305
Static moment rating about Y axis (M 0y) 155
Static moment rating about Z axis (M 0z) 155
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set
Suffix description
B Version
ESC Expanded Design, Short, Narrow Carriage
V1 Slight Preload
G2 Precision Class 2
