INA KWVE25-B-S-V0-G4

Özellikler

Marka	INA
Ürün No	KWVE25-B-S-V0-G4 INA
Üretici No	0114019070150
Alternatif Kodu	KWVE25-B-S-G4-V0
EAN	4054362991052
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	23
Dış (D) MM	48
En (B) MM	83,3
İç (d) Inch	0.9055
Dış (D) Inch	1.8898
En (B) Inch	3.2795
Ağırlık	0.56 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	48
Overall length carriage (L) mm	83,3
Dynamic load rating (C)	17900
Static load rating (C 0)	37000
Static moment rating about X axis (M 0x)	510
Static moment rating about Y axis (M 0y)	395
Static moment rating about Z axis (M 0z)	395
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-S, narrow carriage, four-row

Suffix description

B	Version
S	Narrow Carriage
V0	Little To No Preload
G4	Precision Class 4
