INA KWVE25-W-V1-G4
Fiyatı: 3,059.80 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-W-V1-G4 INA |
| Üretici No | 0665889440250 |
| Alternatif Kodu |
KWVE25-W-G4-V1 |
| EAN | 4054364572365 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 69 |
| Dış (D) MM | 120 |
| En (B) MM | 81,7 |
| İç (d) Inch | 2.7165 |
| Dış (D) Inch | 4.7244 |
| En (B) Inch | 3.2165 |
| Ağırlık | 1.1 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 120 |
| Overall length carriage (L) mm | 81,7 |
| Dynamic load rating (C) | 17900 |
| Static load rating (C 0) | 37000 |
| Static moment rating about X axis (M 0x) | 1470 |
| Static moment rating about Y axis (M 0y) | 395 |
| Static moment rating about Z axis (M 0z) | 395 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly |
| W | Wide Carriage |
| V1 | Slight Preload |
| G4 | Precision Class 4 |
