INA KWVE30-B-ESC-V1-G3

Özellikler

Marka	INA
Ürün No	KWVE30-B-ESC-V1-G3 INA
Üretici No	0171884660240
Alternatif Kodu	KWVE30-B-ESC-G3-V1
EAN	4054362994428
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	28
Dış (D) MM	60
En (B) MM	69
İç (d) Inch	1.1024
Dış (D) Inch	2.3622
En (B) Inch	2.7165
Ağırlık	0.57 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	60
Overall length carriage (L) mm	69
Dynamic load rating (C)	18700
Static load rating (C 0)	31500
Static moment rating about X axis (M 0x)	554
Static moment rating about Y axis (M 0y)	248
Static moment rating about Z axis (M 0z)	248
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set

Suffix description

B	Version
ESC	Expanded Design, Short, Narrow Carriage
V1	Slight Preload
G3	Precision Class 3
