INA KWVE30-B-H-RROC-V1-G3
Fiyatı: 3,824.59 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-B-H-RROC-V1-G3 INA |
| Üretici No | 0782585880240 |
| Alternatif Kodu |
KWVE30-B-H-RROC-G3-V1 |
| EAN | 4054362996071 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| Dış (D) MM | 60 |
| En (B) MM | 99 |
| İç (d) Inch | 1.1024 |
| Dış (D) Inch | 2.3622 |
| En (B) Inch | 3.8976 |
| Ağırlık | 1.04 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 60 |
| Overall length carriage (L) mm | 99 |
| Dynamic load rating (C) | 27500 |
| Static load rating (C 0) | 55000 |
| Static moment rating about X axis (M 0x) | 970 |
| Static moment rating about Y axis (M 0y) | 700 |
| Static moment rating about Z axis (M 0z) | 700 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-H, high, narrow carriage, four-row |
| B | Version |
| H | High Carriage |
| RRF | Components Coated With Corrotect® Containing Cr(VI) |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
