INA KWVE30-B-N-V1-G1

INA KWVE30-B-N-V1-G1
INA KWVE30-B-N-V1-G1 rulman resim 1
INA KWVE30-B-N-V1-G1 rulman resim 2
INA KWVE30-B-N-V1-G1 rulman resim 3
INA KWVE30-B-N-V1-G1 rulman resim 4
INA KWVE30-B-N-V1-G1 rulman resim 5
Fiyatı: 3,475.14 ₺
Özellikler
Marka INA
Ürün No KWVE30-B-N-V1-G1 INA
Üretici No 0199761510220
Alternatif Kodu KWVE30-B-N-G1-V1
EAN 4054362999416
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 28
Dış (D) MM 90
En (B) MM 99
İç (d) Inch 1.1024
Dış (D) Inch 3.5433
En (B) Inch 3.8976
Ağırlık 1 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 90
Overall length carriage (L) mm 99
Dynamic load rating (C) 27500
Static load rating (C 0) 55000
Static moment rating about X axis (M 0x) 970
Static moment rating about Y axis (M 0y) 700
Static moment rating about Z axis (M 0z) 700
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-N, low carriage, four-row
Suffix description
B Version
N Low Carriage
V1 Slight Preload
G1 Precision Class 1
