INA KWVE30-B-V0-G2
Fiyatı: 3,332.75 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE30-B-V0-G2 INA |
| Üretici No | 0171722680130 |
| Alternatif Kodu |
KWVE30-B-G2-V0 |
| EAN | 4054366324153 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 28 |
| İç (d) Inch | 1.1024 |
| Ağırlık | 1.2 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 90 |
| Overall length carriage (L) mm | 99 |
| Dynamic load rating (C) | 27500 |
| Static load rating (C 0) | 55000 |
| Static moment rating about X axis (M 0x) | 970 |
| Static moment rating about Y axis (M 0y) | 700 |
| Static moment rating about Z axis (M 0z) | 700 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B, standard carriage, four-row, full complement ball set |
| B | Version |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
