INA KWVE35-B-EC-V0-G1
Fiyatı: 2,917.81 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-EC-V0-G1 INA |
| Üretici No | 0200582760120 |
| Alternatif Kodu |
KWVE35-B-EC-G1-V0 |
| EAN | 4054366341488 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 100 |
| En (B) MM | 76,2 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 3 |
| Ağırlık | 1.04 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 76,2 |
| Dynamic load rating (C) | 24600 |
| Static load rating (C 0) | 39000 |
| Static moment rating about X axis (M 0x) | 790 |
| Static moment rating about Y axis (M 0y) | 330 |
| Static moment rating about Z axis (M 0z) | 330 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row |
| B | Version |
| EC | Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| V0 | Little To No Preload |
| G1 | Precision Class 1 |
