INA KWVE45-B-L-V1-G2

INA KWVE45-B-L-V1-G2
INA KWVE45-B-L-V1-G2 rulman resim 1
INA KWVE45-B-L-V1-G2 rulman resim 2
INA KWVE45-B-L-V1-G2 rulman resim 3
INA KWVE45-B-L-V1-G2 rulman resim 4
INA KWVE45-B-L-V1-G2 rulman resim 5
Fiyatı: 5,431.09 ₺
Özellikler
Marka INA
Ürün No KWVE45-B-L-V1-G2 INA
Üretici No 0180750880230
Alternatif Kodu KWVE45-B-L-G2-V1
EAN 4054366329981
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 120
En (B) MM 172,7
İç (d) Inch 1.7717
Dış (D) Inch 4.7244
En (B) Inch 6.7992
Ağırlık 4.3 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 120
Overall length carriage (L) mm 172,7
Dynamic load rating (C) 82000
Static load rating (C 0) 181000
Static moment rating about X axis (M 0x) 4635
Static moment rating about Y axis (M 0y) 4000
Static moment rating about Z axis (M 0z) 4000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-L, long carriage, four-row, full complement ball set
Suffix description
B Version
L Long Carriage
V1 Slight Preload
G2 Precision Class 2
