INA KWVE45-B-RROC-V2-G3

Özellikler

Marka	INA
Ürün No	KWVE45-B-RROC-V2-G3 INA
Üretici No	0782232450340
Alternatif Kodu	KWVE45-B-RROC-G3-V2
EAN	4054366882943
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	45
Dış (D) MM	120
En (B) MM	50,3
İç (d) Inch	1.7717
Dış (D) Inch	4.7244
En (B) Inch	1.9803
Ağırlık	3.3 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	120
Overall length carriage (L) mm	140,6
Dynamic load rating (C)	69000
Static load rating (C 0)	141000
Static moment rating about X axis (M 0x)	3610
Static moment rating about Y axis (M 0y)	2485
Static moment rating about Z axis (M 0z)	2485
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B, standard carriage, four-row, full complement ball set

Suffix description

B	Version
RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2	Preload Class 2
G3	Precision Class 3
