INA KBS30-PP-AS Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,530.00 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
30 |
| İç (d) Inch |
1.1811 |
| Ağırlık |
0.3 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
Data from Schaeffler (medias)
| Length (L) mm |
68 |
| Load capacity dyn. (C min) |
3600 |
| Load capacity stat. (C 0 min) |
2850 |
| Load capacity stat. (C 0 max) |
3600 |
| ECLASS number |
23-30-03-01 |
| ECLASS2 number |
23-30-03-01 |
| Medias description |
Linear ball bearings KBS..-PP-AS, machined range, adjustable, sealed on all sides, with relubrication facility, corrosion-resistant design possible |
Suffix description
| PP |
Lip Seal On Both Sides Of Bearing |
| AS |
Lubrication Holes In The Outer Ring Or Lubrication Groove In The Housing |
