INA KN30-B-PP Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,174.02 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
30 |
| Dış (D) MM |
47 |
| En (B) MM |
68 |
| İç (d) Inch |
1.1811 |
| Dış (D) Inch |
1.8504 |
| En (B) Inch |
2.6772 |
| Ağırlık |
0.13 kg
|
Ürün Özellikleri
| Fok |
2L - Her İki Tarafta LS Contası |
Data from Schaeffler (medias)
| Length (L) mm |
68 |
| Load capacity dyn. (C min) |
3750 |
| Load capacity stat. (C 0 min) |
2850 |
| Load capacity stat. (C 0 max) |
3650 |
| ECLASS number |
23-30-03-01 |
| ECLASS2 number |
23-30-03-01 |
| Medias description |
Linear ball bearings KN..-B-PP, Lightweight range, closed design, sealed on all sides, with relubrication facility, adjustable angle |
Suffix description
| B |
Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B |
| PP |
Lip Seal On Both Sides Of Bearing |
