INA KWSE20-H-V1-G2 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,329.89 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
20 |
| Dış (D) MM |
44 |
| En (B) MM |
70,9 |
| İç (d) Inch |
0.7874 |
| Dış (D) Inch |
1.7323 |
| En (B) Inch |
2.7913 |
| Ağırlık |
0.32 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
44 |
| Overall length carriage (L) mm |
71,4 |
| Dynamic load rating, load direction I: compressive load (I C) |
22000 |
| Static load rating, load direction I: compressive load (I C 0) |
52000 |
| Dynamic load rating, load direction II: tensile load (II C) |
21300 |
| Static load rating, load direction II: tensile load (II C 0) |
35300 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
21000 |
| Static load rating, Load direction III: lateral load (III C 0) |
35000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| H |
High Carriage |
| V1 |
Slight Preload |
| G2 |
Precision Class 2 |
