INA KWSE20-L-RROC-V2-G3 Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,352.35 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
20 |
| Dış (D) MM |
63 |
| En (B) MM |
91,6 |
| İç (d) Inch |
0.7874 |
| Dış (D) Inch |
2.4803 |
| En (B) Inch |
3.6063 |
| Ağırlık |
0.6 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
63 |
| Overall length carriage (L) mm |
91,9 |
| Dynamic load rating, load direction I: compressive load (I C) |
28000 |
| Static load rating, load direction I: compressive load (I C 0) |
72000 |
| Dynamic load rating, load direction II: tensile load (II C) |
25000 |
| Static load rating, load direction II: tensile load (II C 0) |
47000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
26000 |
| Static load rating, Load direction III: lateral load (III C 0) |
48000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Long carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| L |
Long Carriage |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
