INA KWSE30-H-RROC-V1-G3 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 5,151.41 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
28 |
| Dış (D) MM |
60 |
| En (B) MM |
91,4 |
| İç (d) Inch |
1.1024 |
| Dış (D) Inch |
2.3622 |
| En (B) Inch |
3.5984 |
| Ağırlık |
0.9 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
60 |
| Overall length carriage (L) mm |
91,6 |
| Dynamic load rating, load direction I: compressive load (I C) |
40000 |
| Static load rating, load direction I: compressive load (I C 0) |
80000 |
| Dynamic load rating, load direction II: tensile load (II C) |
37800 |
| Static load rating, load direction II: tensile load (II C 0) |
60000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
40000 |
| Static load rating, Load direction III: lateral load (III C 0) |
62000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| H |
High Carriage |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V1 |
Slight Preload |
| G3 |
Precision Class 3 |
