INA KWSE35-L-V0-G2

INA KWSE35-L-V0-G2
INA KWSE35-L-V0-G2 rulman resim 1
INA KWSE35-L-V0-G2 rulman resim 2
INA KWSE35-L-V0-G2 rulman resim 3
INA KWSE35-L-V0-G2 rulman resim 4
INA KWSE35-L-V0-G2 rulman resim 5
Fiyatı: 6,547.99 ₺
Özellikler
Marka INA
Ürün No KWSE35-L-V0-G2 INA
Üretici No 0028659710130
Alternatif Kodu KWSE35-L-G2-V0
EAN 4054362955818
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 34
Dış (D) MM 100
En (B) MM 41,4
İç (d) Inch 1.3386
Dış (D) Inch 3.937
En (B) Inch 1.6299
Ağırlık 2.1 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 138,9
Dynamic load rating, load direction I: compressive load (I C) 70000
Static load rating, load direction I: compressive load (I C 0) 145000
Dynamic load rating, load direction II: tensile load (II C) 67500
Static load rating, load direction II: tensile load (II C 0) 119000
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 71000
Static load rating, Load direction III: lateral load (III C 0) 125000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Long carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
L Long Carriage
V0 Little To No Preload
G2 Precision Class 2
