INA KWSE35-V1-G3

INA KWSE35-V1-G3
INA KWSE35-V1-G3 rulman resim 1
INA KWSE35-V1-G3 rulman resim 2
INA KWSE35-V1-G3 rulman resim 3
INA KWSE35-V1-G3 rulman resim 4
INA KWSE35-V1-G3 rulman resim 5
Fiyatı: 4,747.08 ₺
Özellikler
Marka INA
Ürün No KWSE35-V1-G3 INA
Üretici No 0007737190240
Alternatif Kodu KWSE35-G3-V1
EAN 4054362956600
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 34
Dış (D) MM 100
En (B) MM 41,4
İç (d) Inch 1.3386
Dış (D) Inch 3.937
En (B) Inch 1.6299
Ağırlık 1.5 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 107,2
Dynamic load rating, load direction I: compressive load (I C) 55000
Static load rating, load direction I: compressive load (I C 0) 102000
Dynamic load rating, load direction II: tensile load (II C) 53300
Static load rating, load direction II: tensile load (II C 0) 82400
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 56600
Static load rating, Load direction III: lateral load (III C 0) 89150
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Standard carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
V1 Slight Preload
G3 Precision Class 3
