INA KWVE15-B-EC-V2-G1 Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,717.68 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
15 |
| Dış (D) MM |
52 |
| En (B) MM |
44,5 |
| İç (d) Inch |
0.5906 |
| Dış (D) Inch |
2.0472 |
| En (B) Inch |
1.752 |
| Ağırlık |
0.13 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
52 |
| Overall length carriage (L) mm |
44,5 |
| Dynamic load rating (C) |
4900 |
| Static load rating (C 0) |
8300 |
| Static moment rating about X axis (M 0x) |
86 |
| Static moment rating about Y axis (M 0y) |
35 |
| Static moment rating about Z axis (M 0z) |
35 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row |
Suffix description
| B |
Version |
| EC |
Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| V2 |
Preload Class 2 |
| G1 |
Precision Class 1 |
