INA KWVE15-B-H-RROC-V1-G3 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,172.80 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
15 |
| Dış (D) MM |
34 |
| En (B) MM |
61,2 |
| İç (d) Inch |
0.5906 |
| Dış (D) Inch |
1.3386 |
| En (B) Inch |
2.4094 |
| Ağırlık |
0.2 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
34 |
| Overall length carriage (L) mm |
61,2 |
| Dynamic load rating (C) |
7200 |
| Static load rating (C 0) |
14500 |
| Static moment rating about X axis (M 0x) |
150 |
| Static moment rating about Y axis (M 0y) |
100 |
| Static moment rating about Z axis (M 0z) |
100 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-H, high, narrow carriage, four-row |
Suffix description
| B |
Version |
| H |
High Carriage |
| RRF |
Components Coated With Corrotect® Containing Cr(VI) |
| V1 |
Slight Preload |
| G3 |
Precision Class 3 |
