INA KWVE20-B-EC-V1-G3 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 1,782.14 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
20 |
| Dış (D) MM |
59 |
| En (B) MM |
50,4 |
| İç (d) Inch |
0.7874 |
| Dış (D) Inch |
2.3228 |
| En (B) Inch |
1.9843 |
| Ağırlık |
0.23 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
59 |
| Overall length carriage (L) mm |
50,4 |
| Dynamic load rating (C) |
8900 |
| Static load rating (C 0) |
15400 |
| Static moment rating about X axis (M 0x) |
190 |
| Static moment rating about Y axis (M 0y) |
85 |
| Static moment rating about Z axis (M 0z) |
85 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row |
Suffix description
| B |
Version |
| EC |
Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| V1 |
Slight Preload |
| G3 |
Precision Class 3 |
