INA KWVE20-W-UG-V1-G2
Fiyatı: 3,256.66 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE20-W-UG-V1-G2 INA |
| Üretici No | 0096401340230 |
| Alternatif Kodu |
KWVE20-W-UG-G2-V1 |
| EAN | 4054362977469 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 42 |
| Dış (D) MM | 80 |
| En (B) MM | 69,8 |
| İç (d) Inch | 1.6535 |
| Dış (D) Inch | 3.1496 |
| En (B) Inch | 2.748 |
| Ağırlık | 0.5 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 80 |
| Overall length carriage (L) mm | 69,8 |
| Dynamic load rating (C) | 13100 |
| Static load rating (C 0) | 27000 |
| Static moment rating about X axis (M 0x) | 687 |
| Static moment rating about Y axis (M 0y) | 240 |
| Static moment rating about Z axis (M 0z) | 240 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly |
| W | Wide Carriage |
| UG | Un-Greased |
| V1 | Slight Preload |
| G2 | Precision Class 2 |
