INA KWVE20-W-UG-V1-G2 Resim 2
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,256.66 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
42 |
| Dış (D) MM |
80 |
| En (B) MM |
69,8 |
| İç (d) Inch |
1.6535 |
| Dış (D) Inch |
3.1496 |
| En (B) Inch |
2.748 |
| Ağırlık |
0.5 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
80 |
| Overall length carriage (L) mm |
69,8 |
| Dynamic load rating (C) |
13100 |
| Static load rating (C 0) |
27000 |
| Static moment rating about X axis (M 0x) |
687 |
| Static moment rating about Y axis (M 0y) |
240 |
| Static moment rating about Z axis (M 0z) |
240 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly |
Suffix description
| W |
Wide Carriage |
| UG |
Un-Greased |
| V1 |
Slight Preload |
| G2 |
Precision Class 2 |
