INA KWVE25-B-ES-UG-V0-G4
Fiyatı: 2,196.47 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-B-ES-UG-V0-G4 INA |
| Üretici No | 0605502950150 |
| Alternatif Kodu |
KWVE25-B-ES-UG-G4-V0 |
| EAN | 4054362980537 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 48 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 1.8898 |
| Ağırlık | 0.522 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 48 |
| Overall length carriage (L) mm | 83,3 |
| Dynamic load rating (C) | 17900 |
| Static load rating (C 0) | 37000 |
| Static moment rating about X axis (M 0x) | 510 |
| Static moment rating about Y axis (M 0y) | 395 |
| Static moment rating about Z axis (M 0z) | 395 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ES, carriage for four-row linear ball bearing and guideway assembly, expanded type, narrow design |
| B | Version |
| ES | Expanded Design, Narrow Carriage |
| UG | Un-Greased |
| V0 | Little To No Preload |
| G4 | Precision Class 4 |
