INA KWVE25-B-ES-UG-V0-G4 Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,196.47 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
23 |
| Dış (D) MM |
48 |
| İç (d) Inch |
0.9055 |
| Dış (D) Inch |
1.8898 |
| Ağırlık |
0.522 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
48 |
| Overall length carriage (L) mm |
83,3 |
| Dynamic load rating (C) |
17900 |
| Static load rating (C 0) |
37000 |
| Static moment rating about X axis (M 0x) |
510 |
| Static moment rating about Y axis (M 0y) |
395 |
| Static moment rating about Z axis (M 0z) |
395 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-ES, carriage for four-row linear ball bearing and guideway assembly, expanded type, narrow design |
Suffix description
| B |
Version |
| ES |
Expanded Design, Narrow Carriage |
| UG |
Un-Greased |
| V0 |
Little To No Preload |
| G4 |
Precision Class 4 |
