INA KWVE25-B-KD-V2-G3
Fiyatı: 3,639.16 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-B-KD-V2-G3 INA |
| Üretici No | 0239096500340 |
| EAN | 4054362984054 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 70 |
| En (B) MM | 30,9 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 2.7559 |
| En (B) Inch | 1.2165 |
| Ağırlık | 0.68 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 70 |
| Overall length carriage (L) mm | 83,3 |
| Dynamic load rating (C) | 17900 |
| Static load rating (C 0) | 37000 |
| Static moment rating about X axis (M 0x) | 510 |
| Static moment rating about Y axis (M 0y) | 395 |
| Static moment rating about Z axis (M 0z) | 395 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-L, long carriage, four-row, full complement ball set |
| B | Version |
| KD | Components Coated With Protect A Have The Suffix KD (Protect A Is A Pure Chromium Coating With A Columnar Surface Structure). When Using Protect A, Coated Carriages And Coated Guideways Must Always Be Combined. If Coated Carriages Are Used With Uncoated Guideways, For Example, This Will Lead To A Reduction In Preload |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
