INA KWVE25-B-V2-G1
Fiyatı: 2,841.31 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-B-V2-G1 INA |
| Üretici No | 0108317460320 |
| Alternatif Kodu |
KWVE25-B-G1-V2 |
| EAN | 4054362991953 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 70 |
| En (B) MM | 30,9 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 2.7559 |
| En (B) Inch | 1.2165 |
| Ağırlık | 0.68 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 70 |
| Overall length carriage (L) mm | 83,3 |
| Dynamic load rating (C) | 17900 |
| Static load rating (C 0) | 37000 |
| Static moment rating about X axis (M 0x) | 510 |
| Static moment rating about Y axis (M 0y) | 395 |
| Static moment rating about Z axis (M 0z) | 395 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B, standard carriage, four-row, full complement ball set |
| B | Version |
| V2 | Preload Class 2 |
| G1 | Precision Class 1 |
