INA KWVE25-B-N-RROC-V2-G3 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,023.69 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
23 |
| Dış (D) MM |
70 |
| En (B) MM |
83,3 |
| İç (d) Inch |
0.9055 |
| Dış (D) Inch |
2.7559 |
| En (B) Inch |
3.2795 |
| Ağırlık |
0.56 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
70 |
| Overall length carriage (L) mm |
83,3 |
| Dynamic load rating (C) |
17900 |
| Static load rating (C 0) |
37000 |
| Static moment rating about X axis (M 0x) |
510 |
| Static moment rating about Y axis (M 0y) |
395 |
| Static moment rating about Z axis (M 0z) |
395 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-N, low carriage, four-row |
Suffix description
| B |
Version |
| N |
Low Carriage |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
