INA KWVE25-B-SL-V0-G2
Fiyatı: 3,245.23 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE25-B-SL-V0-G2 INA |
| Üretici No | 0127394800130 |
| Alternatif Kodu |
KWVE25-B-SL-G2-V0 |
| EAN | 4054362988410 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 23 |
| Dış (D) MM | 48 |
| En (B) MM | 109,1 |
| İç (d) Inch | 0.9055 |
| Dış (D) Inch | 1.8898 |
| En (B) Inch | 4.2953 |
| Ağırlık | 1 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 48 |
| Overall length carriage (L) mm | 109,1 |
| Dynamic load rating (C) | 23400 |
| Static load rating (C 0) | 54000 |
| Static moment rating about X axis (M 0x) | 745 |
| Static moment rating about Y axis (M 0y) | 825 |
| Static moment rating about Z axis (M 0z) | 825 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-SL, narrow, long carriage, four-row |
| B | Version |
| SL | Narrow, Long Carriage |
| V0 | Little To No Preload |
| G2 | Precision Class 2 |
