INA KWVE25-B-SNL-RROC-V1-G3

Özellikler

Marka	INA
Ürün No	KWVE25-B-SNL-RROC-V1-G3 INA
Üretici No	0772075560240
EAN	4054362989424
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	23
Dış (D) MM	48
En (B) MM	109,1
İç (d) Inch	0.9055
Dış (D) Inch	1.8898
En (B) Inch	4.2953
Ağırlık	0.62 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	48
Overall length carriage (L) mm	109,1
Dynamic load rating (C)	23400
Static load rating (C 0)	54000
Static moment rating about X axis (M 0x)	745
Static moment rating about Y axis (M 0y)	825
Static moment rating about Z axis (M 0z)	825

Suffix description

B	Version
SNL	Narrow, Low, Long Carriage
RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V1	Slight Preload
G3	Precision Class 3
