INA KWVE30-B-EC-RROC-V2-G3 Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 3,281.95 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
28 |
| Dış (D) MM |
90 |
| En (B) MM |
69 |
| İç (d) Inch |
1.1024 |
| Dış (D) Inch |
3.5433 |
| En (B) Inch |
2.7165 |
| Ağırlık |
0.75 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
90 |
| Overall length carriage (L) mm |
69 |
| Dynamic load rating (C) |
18700 |
| Static load rating (C 0) |
31500 |
| Static moment rating about X axis (M 0x) |
554 |
| Static moment rating about Y axis (M 0y) |
248 |
| Static moment rating about Z axis (M 0z) |
248 |
Suffix description
| B |
Version |
| EC |
Expanded Design, Short Carriage (Carriage Without Screw Threads) |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
