INA KWVE30-B-ESC-V1-G4 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,192.59 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
28 |
| Dış (D) MM |
60 |
| En (B) MM |
69 |
| İç (d) Inch |
1.1024 |
| Dış (D) Inch |
2.3622 |
| En (B) Inch |
2.7165 |
| Ağırlık |
0.57 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
60 |
| Overall length carriage (L) mm |
69 |
| Dynamic load rating (C) |
18700 |
| Static load rating (C 0) |
31500 |
| Static moment rating about X axis (M 0x) |
554 |
| Static moment rating about Y axis (M 0y) |
248 |
| Static moment rating about Z axis (M 0z) |
248 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
Suffix description
| B |
Version |
| ESC |
Expanded Design, Short, Narrow Carriage |
| V1 |
Slight Preload |
| G4 |
Precision Class 4 |
