INA KWVE35-B-ESC-RROC-V2-G3 Resim 4

Özellikler

Marka	INA
Ürün No	KWVE35-B-ESC-RROC-V2-G3 INA
Üretici No	0782437180340
Alternatif Kodu	KWVE35-B-ESC-RROC-G3-V2
EAN	4054366883322
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	70
En (B) MM	76,2
İç (d) Inch	1.3386
Dış (D) Inch	2.7559
En (B) Inch	3
Ağırlık	1.04 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	70
Overall length carriage (L) mm	76,2
Dynamic load rating (C)	24600
Static load rating (C 0)	39000
Static moment rating about X axis (M 0x)	790
Static moment rating about Y axis (M 0y)	330
Static moment rating about Z axis (M 0z)	330

Suffix description

B	Version
ESC	Expanded Design, Short, Narrow Carriage
RROC	Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2	Preload Class 2
G3	Precision Class 3
