INA KWVE35-B-ESC-V0-G1 Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,917.81 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
34 |
| Dış (D) MM |
70 |
| En (B) MM |
76,2 |
| İç (d) Inch |
1.3386 |
| Dış (D) Inch |
2.7559 |
| En (B) Inch |
3 |
| Ağırlık |
1.04 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
70 |
| Overall length carriage (L) mm |
76,2 |
| Dynamic load rating (C) |
24600 |
| Static load rating (C 0) |
39000 |
| Static moment rating about X axis (M 0x) |
790 |
| Static moment rating about Y axis (M 0y) |
330 |
| Static moment rating about Z axis (M 0z) |
330 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
Suffix description
| B |
Version |
| ESC |
Expanded Design, Short, Narrow Carriage |
| V0 |
Little To No Preload |
| G1 |
Precision Class 1 |
