INA KWVE35-B-ESC-V0-G2

INA KWVE35-B-ESC-V0-G2
INA KWVE35-B-ESC-V0-G2 rulman resim 1
INA KWVE35-B-ESC-V0-G2 rulman resim 2
INA KWVE35-B-ESC-V0-G2 rulman resim 3
INA KWVE35-B-ESC-V0-G2 rulman resim 4
INA KWVE35-B-ESC-V0-G2 rulman resim 5
Fiyatı: 2,764.40 ₺
Özellikler
Marka INA
Ürün No KWVE35-B-ESC-V0-G2 INA
Üretici No 0174233500130
Alternatif Kodu KWVE35-B-ESC-G2-V0
EAN 4054366325754
Kategori Doğrusal Düz Yatak Birimleri
Ağırlık ve Boyutlar
İç (d) MM 34
Dış (D) MM 70
En (B) MM 76,2
İç (d) Inch 1.3386
Dış (D) Inch 2.7559
En (B) Inch 3
Ağırlık 1.04 kg
Ürün Özellikleri
Fok Kapaksız
Data from Schaeffler (medias)
Width carriage (B) mm 70
Overall length carriage (L) mm 76,2
Dynamic load rating (C) 24600
Static load rating (C 0) 39000
Static moment rating about X axis (M 0x) 790
Static moment rating about Y axis (M 0y) 330
Static moment rating about Z axis (M 0z) 330
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set
Suffix description
B Version
ESC Expanded Design, Short, Narrow Carriage
V0 Little To No Preload
G2 Precision Class 2
