INA KWVE35-B-ESC-V1-G2
Fiyatı: 2,764.40 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-ESC-V1-G2 INA |
| Üretici No | 0174233500230 |
| Alternatif Kodu |
KWVE35-B-ESC-G2-V1 |
| EAN | 4054366325877 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 70 |
| En (B) MM | 76,2 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 2.7559 |
| En (B) Inch | 3 |
| Ağırlık | 1.04 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 70 |
| Overall length carriage (L) mm | 76,2 |
| Dynamic load rating (C) | 24600 |
| Static load rating (C 0) | 39000 |
| Static moment rating about X axis (M 0x) | 790 |
| Static moment rating about Y axis (M 0y) | 330 |
| Static moment rating about Z axis (M 0z) | 330 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| V1 | Slight Preload |
| G2 | Precision Class 2 |
