INA KWVE35-B-S-V1-G4
Fiyatı: 2,972.28 ₺
Özellikler
| Marka | INA |
| Ürün No | KWVE35-B-S-V1-G4 INA |
| Üretici No | 0183558380250 |
| Alternatif Kodu |
KWVE35-B-S-G4-V1 |
| EAN | 4054366333469 |
| Kategori | Doğrusal Düz Yatak Birimleri |
| İç (d) MM | 34 |
| Dış (D) MM | 70 |
| En (B) MM | 112 |
| İç (d) Inch | 1.3386 |
| Dış (D) Inch | 2.7559 |
| En (B) Inch | 4.4094 |
| Ağırlık | 1.3 kg |
| Fok | Kapaksız |
| Width carriage (B) mm | 70 |
| Overall length carriage (L) mm | 112 |
| Dynamic load rating (C) | 38000 |
| Static load rating (C 0) | 72000 |
| Static moment rating about X axis (M 0x) | 1465 |
| Static moment rating about Y axis (M 0y) | 1020 |
| Static moment rating about Z axis (M 0z) | 1020 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-S, narrow carriage, four-row |
| B | Version |
| S | Narrow Carriage |
| V1 | Slight Preload |
| G4 | Precision Class 4 |
