INA KWVE35-B-SN-V2-G2

Özellikler

Marka	INA
Ürün No	KWVE35-B-SN-V2-G2 INA
Üretici No	0200548150330
Alternatif Kodu	KWVE35-B-SN-G2-V2
EAN	4054366341235
Kategori	Doğrusal Düz Yatak Birimleri

Ağırlık ve Boyutlar

İç (d) MM	34
Dış (D) MM	70
En (B) MM	112
İç (d) Inch	1.3386
Dış (D) Inch	2.7559
En (B) Inch	4.4094
Ağırlık	1.24 kg

Ürün Özellikleri

Fok

Kapaksız

Data from Schaeffler (medias)

Width carriage (B) mm	70
Overall length carriage (L) mm	112
Dynamic load rating (C)	38000
Static load rating (C 0)	72000
Static moment rating about X axis (M 0x)	1465
Static moment rating about Y axis (M 0y)	1020
Static moment rating about Z axis (M 0z)	1020
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-SN, narrow, low carriage, four-row

Suffix description

B	Version
SN	Narrow, Low Carriage
V2	Preload Class 2
G2	Precision Class 2
