INA KWVE55-B-L-RROC-V1-G3 Resim 5
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 14,227.78 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
53 |
| Dış (D) MM |
140 |
| En (B) MM |
211,6 |
| İç (d) Inch |
2.0866 |
| Dış (D) Inch |
5.5118 |
| En (B) Inch |
8.3307 |
| Ağırlık |
6.6 kg
|
Ürün Özellikleri
Data from Schaeffler (medias)
| Width carriage (B) mm |
140 |
| Overall length carriage (L) mm |
211,6 |
| Dynamic load rating (C) |
127000 |
| Static load rating (C 0) |
285000 |
| Static moment rating about X axis (M 0x) |
7500 |
| Static moment rating about Y axis (M 0y) |
4725 |
| Static moment rating about Z axis (M 0z) |
4800 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-L, long carriage, four-row, full complement ball set |
Suffix description
| B |
Version |
| L |
Long Carriage |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V1 |
Slight Preload |
| G3 |
Precision Class 3 |
